MNR 190 Vacuum Pump kits for pressure controllers and piston gauges

Vacuum pump kits for pressure controllers and piston gauges

When you perform absolute or negative gauge calibrations, you need an effective vacuum set up. Our Minerva vacuum pumps provide the required performance you can trust. They come with an easy plug and play kit in which all parts you need for your equipment are supplied, including
the connection hose. A perfect match for your controller or piston gauge. For the MNR-190-Refer high capacity vacuum kit, we also supply the vacuum hose with the KF fittings.

MNR-190 Basic Vacuum Kit: Suitable for Fluke/DHI/Ruska controllers 2271A, 6270A, 7250, 7250i, 7250xi, 7252, 7252i and PPC4
MNR-190 Reference Vacuum Kit: Suitable for Fluke/DHI/Ruska piston gauges 2465A, 2468A, PG7601, PG9602/9607 and Minerva NGP MNR-700-NGP



Very effective vacuum pumps specifications

The Minerva MNR-190 vacuum pumps work quickly and generate a solid vacuum within a few seconds, see below graph. These graphs show how quickly the pump reaches a certain vacuum in relation to the connected volume.

MNR 190 Basic Vacuum Kit









MNR 190 Reference Vacuum Kit

General specifications



MNR 190 Basic Vacuum Kit

MNR 190 Reference Vacuum Kit

Nominal displacement

6,0 m3/H

32,5 m3/H

Ultimate pressure

3x 10-3 mbar

4x 10-3 mbar

Motor power

250 W

1,1 kW

Oil capacity Ltr

0,35

1,8

Weight

11,2 kg

39 kg

Ambient temperature

10-40 °C

10-40 °C



Connections Inlet

8 mm OD hose

25 KF (DIN)

Dimensions pump LxWxH

335 x 138 x 250 mm

565 x 205 x 296 mm

Supplied with:

3-way valve, smoke eliminator Exhaust filter, power failure and interconnection kit

pumping valve, connecting hose

Ordering code

MNR-190-Bas Vac Kit

MNR-190-Refer Vac Kit
